| Place of Origin: | Shaanxi, China |
| Brand Name: | Razorlux |
| Certification: | ce, LVD, RoHS, Saa, UL |
| Model Number: | RGL2-1000P |
| Price: | $10.00 - $1,652.00/Pieces |
|---|---|
| Packaging Details: | 1.EPS Foam+carton(ONE UNIT PER CARTON) <br>2.Carton Size(mm):550*450*560mm<br>3.One 20'' Container can accept 250 Units |
| Color Temperature(CCT): | 5000K (Daylight), Cool White | Lamp Luminous Efficiency(lm/w): | 120, 120 |
|---|---|---|---|
| Color Rendering Index(Ra): | 80 | Support Dimmer: | YES |
| Lighting Solutions Service: | DIALux Evo Layout, Agi32 Layout, Auto CAD Layout | Product Weight（kg）: | 30 |
| Input Voltage(V): | 80~305Vac,180-528vac | CRI (Ra>): | 75 |
| Beam Angle(°): | 15° 20° 30° | Working Lifetime(Hour): | 50000 |
| Lamp Body Material: | Aluminum Alloy | Application: | Sports Stadiums |
| Light Source: | LED | Lamp Luminous Flux(lm): | 120000lm |
| Working Temperature(℃): | -40 To 60, -40 - 60 | Product Name: | Sports Light Fixture |
| Housiong Material: | Aluminum | IP Class: | IP 65 (Upgradeable To IP 67) |
| LED Driver: | Meanwell | ||
| Highlight: | 5000K sports light fixture,120000lm sports light fixture,1000w led stadium lights |
||
| 1. 80% lumen maintenance over 50,000hours |
| 2. Wide Power range: 1000W |
| 3. 110-480Vac input voltage without additional adapter |
| 4. Patent Built-in Serge Protection. |
| 5. Top chips high efficacy 120lm/w with meanwell driver |
| 6. IP67 waterproof, IK10 impact proof |
| 7. Neutral Salt Spray Resistance |
| 8. Anti-Corression power coating surface treatment |
| 9. Stainless steel brackets material.(Upgradable to SS316) |
| 10. 0-10VDC, DALI and wireless control available |
| 11. UL cUL DLC, TUV CE RoHS, CB, SAA, LM79 listed |
| 12. High uniformity & color rendering index |
Parameters:
| Model | RGL-1000P | |
| Beam Angle | 15° 20° 30° | |
|
Stable Flux (5700K after 1 hour) |
120000lm | |
| Dimension (mm) | 671*405*379 | |
| LEDs | 900W | |
| Power | Driver | 100W |
| Consumption | Total | 800W |
| Replace HID Lamp | 2200~2500W | |
| Net Weight | 38kg with stainless steel floodlight bracket with driver box | |
| Color Temperature | 2700-6500K | |
| Color Rendering | ≥Ra75 (≥Ra80, ≥Ra90 available on request) | |
| Working Life | ≥50000Hrs | |
| Housing Material | Aluminum & Powder coating | |
| Power Supply | Meanwell | |
| IP Class |
IP 65 (Upgradeable to IP 67) |
|
| IK Class |
IK 10 |
|
| Insulation Class | Class I | |
| Working Temperature | -40C ~ 60C / -40F ~ 140F | |
| Working Humidity | 10% ~ 95% | |
| AC Input | 80-305Vac input voltage without additional adapter | |
| DC Input | 100 ~ 400Vdc, 500Vdc ~ 800Vdc | |
| THD | <10% | |
| Power Factor | ≥0.98 | |
| Warranty | LED Module | 5 year |
| Driver | 5 year | |
| Housing | 10 year | |
For Different application requirement, Razorlux Genius Series have different types of beam angles options.
at the moment we have 15° 20° 40° 60° 120° 140° beam angle available.
For Different application requirement, Razorlux Genius Series have different types of beam angles options.
at the moment we have 15° 20° 40° 60° 120° 140° beam angle available.
FAQ
Q1. Are you a factory?
YES, our factory in XI'AN established in 2010 with 50 workers and 10 engineers.
Q2. : Color temperature of the outdoor led high mast light?
3000/3500/4000/4500/5000/5700/6000/6500K
Q3: Certificates for the outdoor led high mast light?
CE(EMC + LVD) SAA ROHS UL DLC
Q4: How long is the lifetime for the outdoor led high mast light?
50,000HOURS
Q5: Lumens of the outdoor led high mast light?
100-130 LM/W Differs with different series
Q6: Warranty for the outdoor led high mast light?
5 years warranty depends on customers requests
Q7: What lamps can be replaced with the outdoor led high mast light?
Halogen,HPSL & compact fluorescent lamps.
Q8: Any intelligent options for the outdoor led high mast light?
0-10V PWM DALI PLC light control
Q9: Any OEM accessories can be provided when the standard one does not work for installation?
Yes, OEM/ODM support for the different application request.
Q10: Can I have our LOGO on the products and packages?
A: Yes.
Q11: How to deal with the faulty?
Our products are produced in a strict quality control system and the defective rate is less than 0.2%.
If a Quality problem happens, Return/Refund policy according to warranty agreement.
